GENERAL
Type: Amateur VHF/UHF transceiver
Frequency range: Europe
TX: 144-146 / 430-440 MHz
RX: 108-1000 MHz
USA
TX: 144-148 / 430-450 MHz
RX: 108-1000 MHz (Cellular blocked)
Tuning steps: 5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz
Frequency stability: ±5 ppm @ -10 to +60°C (14 to 140°F)
Mode: TX: FM / NFM
RX: AM / FM / NFM
Channels / memory management: 1000 regular with alpha tags (6 characters)
5 home
5 hyper
10 NOAA weather channels
50 scan edge pairs (PMS)
Priority function
Non-volatile EEPROM storage
Repeater shift / offset: ±0-99.95 MHz in 50 KHz steps
Power supply: 13.8 VDC ±15% ("T" connector on pigtail)
Current drain / power consumption: RX: 200-450 mA
TX: Max 8.5 A
Antenna impedance / connector: 50 ohm / N-jack
Dimensions (W*H*D): 140*42*168 mm (5.51*1.65*6.61")
Weight: 1 Kg (2.2 lb)
Other features: CTCSS/PL and DCS with tone search. WIRES. ARS. ARTS. Dimmer.
1K2/9K6 packet jack. Data cloning. Detachable front panel.




RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 45.05 MHz
2nd IF: 450 KHz
Sensitivity: AM (10 dB S/N)
108-137 MHz: 0.8 uV
300-336 MHz: 0.8 uV
FM (12 dB SINAD)
137-150 MHz: 0.2 uV
150-174 MHz: 0.25 uV
174-222 MHz: 0.3 uV
222-300 MHz: 0.25 uV
336-420 MHz: 0.25 uV
420-520 MHz: 0.2 uV
800-900 MHz: 0.4 uV
900-1000 MHz: 0.8 uV
Selectivity: 12 KHz (-6 dB)
30 KHz (-60 dB)
Image rejection:
AF output power / speaker: 2 W at 10% distortion / 8 ohm
External speaker connector: 3.5 mm, 4-16 ohm




TRANSMITTER SECTION
RF output power:

High Low 3 Low 2 Low 1
2 m: 50 W 20 W 10 W 5 W
70 cm: 40 W 20 W 10 W 5 W
Modulation system: Variable reactance
Max FM deviation (Factory set): FM: ±5 KHz
NFM: ±2.5 KHz
Spurious emissions: Better than -60 dB
Microphone impedance / connector: 2 Kohm / 6-pin (Modular)
Microphone input level: ? mV




MISCELLANEOUS
Manufactured: Japan, 2003-2009 (Discontinued)
Additional info:
Related documents: User manual (2.9 MB)
Modifications and fixes:
Reviews:
Options / Accessories:
CT-39
FP-1023
FP-1030A
MEK-2
MH-42B6JS
MH-48A6J
MLS-100
MMB-36
YSK-7800 Packet interface cable
AC power supply. 13.8 VDC, 23 A (USA only)
AC power supply. 13.8 VDC, 25 A
Microphone extension kit
Hand microphone
Hand microphone with DTMF keypad
External speaker
Mobile mouonting bracket
Separation kit
